Features
● It is forged by special alloy steel with high intensity and high toughness, and then it is heat treated;
● It can be matched with sling and G80 chains which can meet the standard EN818-2;
● Each workpiece should pass testing at 2.5 times of working load limit;
● We should carry out sampling and 20000 times of fatigue testing;
● We should carry out strict sampling and breakage testing for each batch of products;
● We should carry out 100% magnetic powder flaw detection;
● 100% of the pin should be tested to ensure that they have the same hardness;
● Color code: red RAL3020/yellow RAL1003.
● Surface treatment: plastics spraying.
| Item Code | Weight (kg) | Woring Load Limit (t) | Breaking Load (t) | B±2 | C±2 | D±1 | L±3 | T±1.5 | E±2 |
| 8-SLR042-06 | 0.71 | 1.12 | 4.48 | 32.5 | 34.8 | 11.5 | 163.3 | 34 | 27 |
| 8-SLR042-7/8 | 1.1 | 2 | 8 | 36 | 40 | 13 | 195.2 | 46 | 35 |
| 8-SLR042-10 | 2.0 | 3.15 | 12.6 | 42 | 48 | 15.5 | 237 | 56 | 44 |
| 8-SLR042-13 | 4.0 | 5.3 | 21.2 | 50 | 58 | 17 | 282 | 69 | 53 |
| 8-SLR042-16 | 7.3 | 8 | 32 | 61 | 61 | 21.5 | 341.5 | 86 | 60 |
| 8-SLR042-20 | 11.6 | 12.5 | 50 | 76 | 75.5 | 26.5 | 399.5 | 100 | 87 |
| 8-SLR042-22 | 16.0 | 15 | 60 | 97 | 97 | 33 | 461 | 98 | 80 |
| 8-SLR042-26 | 21.5 | 21.2 | 84.8 | 123 | 115 | 42 | 536.5 | 110 | 98 |
